This is the innovative Walbro F90000285 39/50 Fuel Pump. This DCSS 39/50 pump features a single impeller with two parallel rows of turbine blades. F90000285 is designed for high performance and supports 800 horsepower engines. With a super charger the exceptional dual pumping channel design delivers maximum pressure with superior fuel flow. The F90000285 operates with a flex fuel system and comes with a check valve to avoid system leak-down and extended cranking at start-up. This superior design results in improved hot fuel flow as well as minimal noise. This increases efficiency by 20% over conventional pumps, delivering unparalleled performance.
Features:
- Capable of supporting 900+HP at 60 psi naturally aspirated applications
- E85 compatible
- Featuring award winning DCSS technology
- High pressure relief setting with support supercharger and turbo applications
- Internal check valve
- Recommended for boosted: Yes
Specifications:
- Pump type: In-tank
- Fuel type: Flex
- Flow: 525 lph
- Flow Rate: 470 lph @ 40 psi
- Fuel Pressure: 40 psi
- Horsepower: 800
- Maximum working pressure: 125
- Amperage rating: 19.0 @ 40 psi
- Test Voltage: 13.5 Volts
- Inlet:
- Size: 11.00 mm
- Type: Turbine inlet
- Outlet:
- Size: 11.00 mm
- Type: Dual barbed
QFS install kit options available.
- Brand Name:
- Walbro / TI Automotive
No Fitment Found
There is a Limited warranty on all Walbro/TI Automotive products. Any Walbro or TI Automotive products that fail prematurely may qualify for replacement if it is determined that the failure was due to a defect in workmanship or material. This warranty only applies to the original customer and is non-transferable. Improper use, installation, or repair of the product voids this warranty, and Quantum Fuel Systems is not responsible for incidental costs resulting from the failure of the product. Quantum Fuel Systems will provide one (1) warranty replacement of the original Walbro or TI Automotive product within sixty (60) days of the original purchase date. All warranty claims placed beyond this 60-day period will need to be sent directly to Walbro/TI Automotive. Please visit www.highflowfuel.com/contact for assistance. Alternatively, Quantum Fuel Systems will offer to replace a Walbro/TI Automotive pump outside of the 60-day period with a Quantum Fuel Systems manufactured pump that is interchangeable with the original pump purchased. Please note that Quantum Fuel Systems does not manufacture an interchangeable pump for all Walbro/TI Automotive pumps and this option is subject to availability of the product.
